Power Factor Controller NV-5,NV-7

- Micro-processor based
- Cos φ and power factor info
- LED indication for individual step
- Auto C/K detection
- Auto or manual operation
- Auto detection of C.T. polarity
- Secondary current info
- Voltage & Frequency info
- THD-I and THD-V info
- Programmable over voltage alarm
- Alarm or fan output
- Programmable software lock
- Flush mount
      Technical data
        Power supply                 	240VAC
Rated current ../5A
Rated frequency 47 ~ 63Hz
Output relay/Alarm 5A / 250VAC
No voltage release < 40 ms
Weight approx. 460g
Operating temp. 0°C ~ +55°C
Standard IEC:61000-4-2/4-4/4-5/255-5:1
      Setting Range
	C/K value			Auto or 0.02 ~ 1.00
Cos φ 0.85(ind) ~ 0.95(cap)
Switching program Auto or P-0 ~ P-6 or custom
Switching interval 2 ~60 sec.
(V) > over voltage OFF or 240 ~ 270V
